US Patent #9809955
![Slot Wall Ties Slot Wall Ties](https://cdn.forconstructionpros.com/files/base/acbm/fcp/image/2012/12/960w/hlfx-tw9_10842722.jpg)
Sure Tie (#4520) quickly and accurately pierces insulation and/or wallboard to abut with steel studs in brick veneer applications.
![Slot Wall Ties Slot Wall Ties](https://image.made-in-china.com/202f0j00ZntELOdPLgcF/Channel-Slot-Anchor-Bolt.jpg)
![Slatwall Slatwall](https://www.twistfix.co.uk/images/pictures/faq/how-to-repair-cracked-walls/how-are-wall-stitching-bars-installed-5-(content-regular-width).png?v=298ac61d&mode=h)
Slot Wall Strip
SureTie allows positive contact with steel stud backup. Compression and tension loads in the veneer are transferred to the steel stud backup.
The adjustable SureTie triangle (#4510) allows a maximum of 1-1/4″ vertical movement both up and down.
SureTie holds insulation in place, permitting contractors to install 4'x 8' sheets with ease, saving time and money.
Features:
- Wide Slot to accept a Hook instead of a Triangle allows for faster and easier installation.
- Maximum clearance between connecting parts of the tie is 1/16″.
- High strength barrel and slotted head fabricated from carbon steel.
- Manufactured and tested in conformance with SAE J78 (self-drilling and self-tapping screws).
- One-piece design provides superior strength.
- 12-24 self driller (#4522).
- Accommodates Various thicknesses of insulation.
- Silver-gray Climaseal® finish resulted in 0% red rust at 1000 hours exposure to ASTM B-117 salt spray testing.
Sizes:
Part | Length | Gauge |
---|---|---|
#4522 SureTie | Can accommodate up to 4-1/2' of insulation | #12-24 self driller |
#4510 SureTie Triangle | 3' 4' 5' 7' 9' | 3/16' dia. standard |
